Name: Ursalink UR35 Industrial 3G/4G/LTE PoE router with WiFi
Brand: Milesight IoT
SKU: UR35-L00AU-W-P
Price: 599.15 NZD
Availability: InStock

Ursalink industrial PoE router front panel with GPS and AUX ports, LAN 1-4 and WAN

Ursalink UR35 Industrial 3G/4G/LTE PoE router with WiFi

UR35-L00AU-W-P

$599.15

Tax included.

In stock, ready to be shipped

Select quantity

Description

Ursalink UR35 Industrial 3G/4G/LTE PoE router with WiFi

Description

Ursalink UR35 Industrial 3G/4G/LTE PoE router with WiFi

The Ursalink UR35 is a cost-effective industrial cellular router with embedded intelligent software features that are designed for multiple M2M/IoT applications. Global WCDMA and 4G LTE carrier support makes this device a must-have for operators trying to maximizing uptime.

Integrating an embedded cellular modem and dual SIM functionality, the UR35 provides 3G/4G cellular network speeds up to150 Mbps download and 50 Mbps upload, it also has 5 Ethernet ports and supports 802.11b/g/n Wi-Fi.

All of these capabilities deliver uninterrupted internet access. Easy deployment and comprehensive remote device management makes the UR35 versatile in most IoT/M2M applications.

. .

Features

Dual SIM cards for backup between multiple carriers
Ethernet, I/O, serial port and Wi-Fi for connecting end devices.
Ursalink DeviceHub connectivity
Embedded Python SDK for development
Rugged enclosure, optimized for DIN rail or shelf mounting
3-year warranty included

Details
Product Code	UR35-L00AU-W-P
CPU	528 MHz, ARM Cortex A7z
Memory	128 MB Flash, 128 MB DDR3 RAM
SIM Slots	2
Storage	1 × Micro SD
Ports	5 × RJ-45 (1 × WAN +4 × LAN (PoE PSE Optional on LAN ports)
Connectors	2 x SMA, 1 x RP-SMA
Ports	1 × RS232 + 1 × RS485 (Terminal Block)
Input Voltage	9-48 VDC (48 V power input is needed for PoE output)
Power Consumption	? 7.9W (In Non-PoE mode)
Serial Interface	1 × RS232 + 1 × RS485 (2 × RS485 Optional)
Baud Rate	300bps to 230400bps
Power Output	4 × 802.3 af/at PoE output
Ingress Protection	IP30
Dimensions	135 x 103 x 45 mm (5.31 x 4.06 x 1.77 in)
Mounting	Desktop, Wall or DIN Rail Mounting
Network Protocols	PPP, PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, RIPv1/v2, OSPF, DDNS, VRRP, HTTP, HTTPS, DNS, ARP, QoS, SNTP, Telnet, VLAN, SSH
Serial Port	Transparent (TCP Client/Server, UDP), Modbus Gateway (Modbus RTU to Modbus TCP)
Operating Temp	-40°C to +70°C (-40? to +158?) Reduced Cellular Performance Above 60°C
Storage Temp	-40°C to +85°C (-40? to +185?)
Freq Bands	3G: B1/B2/B5/B8 WCDMA, 4G: B1/B2/B3/B4/B5/B7/B8/B28@FDD LTE, B40@TDD LTE

IoT Academy

Details
Contents	Power supply, Ethernet Cable, Terminal Block, Mounting Bracket, 2 x Mobile antenna, 1 x WiFi antenna, Warranty Card

Warranty

3 Years

Brand

Milesight IoT

Restock ETA (if applicable)

Product Details

Specifications

Milesight IoT
HeadingUrsalink UR35 Industrial 3G/4G/LTE PoE router with WiFi

Description

Ursalink UR35 Industrial 3G/4G/LTE PoE router with WiFi

Description

Ursalink UR35 Industrial 3G/4G/LTE PoE router with WiFi

Features

Dual SIM cards for backup between multiple carriers
Ethernet, I/O, serial port and Wi-Fi for connecting end devices.
Ursalink DeviceHub connectivity
Embedded Python SDK for development
Rugged enclosure, optimized for DIN rail or shelf mounting
3-year warranty included

Details
Product Code	UR35-L00AU-W-P
CPU	528 MHz, ARM Cortex A7z
Memory	128 MB Flash, 128 MB DDR3 RAM
SIM Slots	2
Storage	1 × Micro SD
Ports	5 × RJ-45 (1 × WAN +4 × LAN (PoE PSE Optional on LAN ports)
Connectors	2 x SMA, 1 x RP-SMA
Ports	1 × RS232 + 1 × RS485 (Terminal Block)
Input Voltage	9-48 VDC (48 V power input is needed for PoE output)
Power Consumption	? 7.9W (In Non-PoE mode)
Serial Interface	1 × RS232 + 1 × RS485 (2 × RS485 Optional)
Baud Rate	300bps to 230400bps
Power Output	4 × 802.3 af/at PoE output
Ingress Protection	IP30
Dimensions	135 x 103 x 45 mm (5.31 x 4.06 x 1.77 in)
Mounting	Desktop, Wall or DIN Rail Mounting
Network Protocols	PPP, PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, RIPv1/v2, OSPF, DDNS, VRRP, HTTP, HTTPS, DNS, ARP, QoS, SNTP, Telnet, VLAN, SSH
Serial Port	Transparent (TCP Client/Server, UDP), Modbus Gateway (Modbus RTU to Modbus TCP)
Operating Temp	-40°C to +70°C (-40? to +158?) Reduced Cellular Performance Above 60°C
Storage Temp	-40°C to +85°C (-40? to +185?)
Freq Bands	3G: B1/B2/B5/B8 WCDMA, 4G: B1/B2/B3/B4/B5/B7/B8/B28@FDD LTE, B40@TDD LTE
