Name: Tycon Power Systems TP-VRHP-2456 Voltage Regulator 18-36VDC input, 56VDC 1.25A 70W Output
Brand: Tycon Power
SKU: TP-VRHP-2456
Price: 241.50 NZD
Availability: InStock

Tycon Power Systems TP-VRHP-2456 Voltage Regulator 18-36VDC input, 56VDC 1.25A 70W Output

TP-VRHP-2456

$241.50

Tax included.

6 items available

Select quantity

Description

Tycon Power Systems TP-VRHP-2456 Voltage Regulator 18-36VDC input 56VDC 1.25A 70W Output

Tycon Power Systems TP-VRHP-2456 Voltage Regulator 18-36VDC input, 56VDC 1.25A 70W Output.

The TP-VRHP series of DC to DC converters offer high output voltage conversion in a compact metal enclosure. They have wire terminal inputs and outputs for maximum flexibility. The units come with DIN rail adapters for DIN rail mounting.

Features

High Output, Short Circuit Protected
Metal Enclosure, DIN rail mounting
Industrial Temperature Operation
Most Models Isolated Input to Output
Low Voltage Disconnect

Details
Manufacturer's Product Code	TP-VRHP-2456
DC Input Voltage Range	+/- 18 to 36VDC
DC Voltage Output	56VDC @ 1.25A
Maximum Power	70W
Input / Output Isolation	Isolated
Efficiency	Better then 85%
Load / Line Reg	5% / 1%
Ripple / Noise	2% / 5%
Isolation	1500VDC Min. / 100M Ohms Min
Wire Gauge	12AWG Max
Protections	Short Circuit, Overvoltage, Overload
Operating Temp	-22°F to 149°F (-30°C to +65°C)
Operating Humidity	0 to 90% RH
Size	5.24 x 3 x 1.5” (133x75x38mm)
Weight	298g

support

Details
Included	Regulator, Din Rail mount Kit

Warranty

1 Year

Brand

Tycon Power

Restock ETA (if applicable)
