Omada PoE++ Injector

2 × 10Mbps/100Mbps/1Gbps/2.5Gbps/5Gbps/10Gbps RJ45 Ports ensure faster transmission
Complies with IEEE802.3af/at/bt standards, supplies up to 60 W
Reduces infrastructure costs by transmitting data and power simultaneously via an Ethernet cable
Automatically determines and supplies the exact power to meet the device's need
Wall-mounting and desktop design accommodates most installation scenarios
Plug & Play installation, no configuration required
Integrated power supply
Durable metal casing

What This Product Does

The Omada PoE++ Injector POE370S fully complies with IEEE 802.3af/at/bt (type 3) standards with up to 60 W power supply.* It can easily expand your network to where there are no power lines or outlets, ideal for connecting PTZ IP Cameras, access points, and LEDs.

HARDWARE FEATURES
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3an
Interface	2 × 10Mbps/100Mbps/1Gbps/2.5Gbps/5Gbps/10Gbps RJ45 Ports
Network Media	• 10Base-T/100Base-TX: UTP category 5 cable or above (maximum 100 m) • 1000Base-T/2.5GBase-T: UTP category 5e cable or above (maximum 100 m) • 5GBase-T: UTP category 5e cable or above (maximum 100 m) • 10GBase-T: UTP category 6 cable or above (maximum 50 m) STP category 6a cable or above (maximum 90 m)
Max. Power Consumption	60 W
LED	PWR, PoE
Dimensions ( W x D x H )	154.7 × 70 × 42 mm (6.09 × 2.76 × 1.65 in)

OTHERS
Certification	FCC, CE
Package Content	• POE370S • Power Cord • Installation Guide
Environment	• Operating Temperature: -5°C to 45°C (23°F to 113°F)ether • Storage Temperature: -40°C to 70°C (-40°F to 158°F) • Operating Humidity: 10% to 90%RH non-condensing • Storage Humidity: 5% to 90%RH non-condensing

For additional version information, please go to the support page.

*POE370S is incompatible with Passive PoE and other non-standard PoE devices. The standards refer to IEEE 802.3af/at/bt.
