TP-Link EAP650 D30-Outdoor AX3000 Indoor/Outdoor Wi-Fi 6 Access Point Default Title

TP-Link EAP650 D30-Outdoor AX3000 Indoor/Outdoor Wi-Fi 6 Access Point

TP-Link EAP650 D30-Outdoor AX3000 Indoor/Outdoor Wi-Fi 6 Access Point

TL-EAP650D30-OUTDOOR

$444.35

Tax included.

Out of stock

Select quantity

Description

AX3000 Indoor/Outdoor Wi-Fi 6 Access Point

Superior Wi-Fi 6 Speeds: 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz.^†
Directional Ultra-Range Coverage: Equipped with built-in high-gain directional antennas to deliver precise and extended coverage.*
Ideal for Warehouses and Outdoor Scenes: Features an IP68 waterproof enclosure with -30°C to +70°C operating range.
802.11k/v/r Seamless Roaming: Ensures uninterrupted connectivity for AGVs and handheld scanners.^§
Flexible Deployment: Supports 802.3at PoE and Omada Mesh technology.
Centralised Cloud Management: Control everything from a single interface anywhere via the Omada app or Web UI.^§

Designed for Warehouses

The EAP650 D30-Outdoor features a durable, fully sealed IP68 weatherproof enclosure, making it dustproof and capable of withstanding submersion in water. It is ideal for warehouse environments.

Durable Waterproof
Enclosure
Operating Temperature
of -30°C to 70°C
No Ingress
of Dust

Warehouse Shelving Areas
Storehouses

Elevate Wi-Fi Experience for Shelf Areas with Directional Antennas

Equipped with 4× built-in dual-band directional antennas with high gain to ensure the optimal Wi-Fi experience ideal for precise and extended coverage.*

Recommended Installation Height

13 ft / 4 m
Recommended Coverage Length

262 ft / 80 m

Higher Installation

Longer Coverage

Less Disruption

Directional Antennas for
Ultra-Range Coverage in Outdoor Scenarios

2.4 GHz up to

1181 ft /360 m*
5 GHz up to

2953 ft /900 m*

*Based on field tests in an open, outdoor, and unobstructed environment. The number listed here is the maximum distance of one EAP650 D30-Outdoor which the client's signal strength is ≥ -75 dBm. The real transmission range and recommended coverage may vary, according to the environment, receiving device, etc.

Stay Smooth with Seamless Roaming

Ensure users enjoy uninterrupted steaming when moving around by switching clients automatically to the access points with the optimal signals.

Seamless Roaming

Seamless Integration into Omada SDN

On-Premises Controllers

Omada Cloud-Based Controller^△

Omada Hardware Controller

Omada Software Controller

Wi-Fi 6 Indoor/Outdoor AP

EAP650 D30-Outdoor

Omada PoE Switch

Omada VPN Gateway

Internet

Cloud Access

Web Browser

Omada App

† Maximum wireless transmission rates are the physical rates derived from IEEE Standard 802.11 specifications. Range, coverage, and maximum quantity of connected devices are based on test results under normal usage conditions. Actual wireless data throughput, wireless coverage, and quantity of connected devices are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection quality, and client condition.

§Omada Mesh, Seamless Roaming, Cloud Access, and Captive Portal require the use of an Omada controller.

*Coverage is calculated based on laboratory testing. Actual coverage is not guaranteed and will vary as a result of client limitations and environmental factors.

**The actual capacity depends on the wireless environment and client traffic and is generally less than the maximum number of client connections.

HARDWARE FEATURES
Interface	1× Gigabit Ethernet Port (supports 802.3at PoE or 48V Passive PoE)
Button	Reset
Power Supply	• 802.3at PoE • 48V Passive PoE
Max. Power Consumption	• EU: 12.5W (802.3at PoE or Passive PoE) • US: 14.7W (802.3at PoE or Passive PoE)
Dimensions ( W x D x H )	8.2 × 2.3 × 9.1 in (207.5 × 58 × 230 mm)
Antenna	Built-in Directional Antennas: • 2.4 GHz: 2× 12 dBi • 5 GHz: 2× 15 dBi Beamwidth: 30° Horizontal; 30° Vertical
Bluetooth	Yes
Weatherproof Enclosure	IP68
Mounting	Wall/Pole/Ceiling Mount

WIRELESS FEATURES
Concurrent Clients	250+^**
Wireless Standards	IEEE 802.11 a/b/g/n/ac/ax
Frequency	2.4 GHz, 5 GHz
Signal Rate	574 Mbps (2.4 GHz) + 2402 Mbps (5 GHz)†
Wireless Functions	• 1024-QAM • DL/UL OFDMA • Multiple SSIDs (Up to 16 SSIDs, 8 on each band) • Enable/Disable Wireless Radio • Enable/Disable SSID Broadcast • Guest Network • Automatic Channel Assignment • Transmit Power Control (Adjust Transmit Power on dBm) • QoS (WMM) • 2 × 2 (2.4 GHz & 5 GHz) DL/UL MU-MIMO • Omada Mesh^§ • Seamless Roaming(802.11k/v/r)^§ • Band Steering • Load Balance • Airtime Fairness • Beamforming • RADIUS Accounting • MAC Authentication • Reboot Schedule • Wireless Schedule • Wireless Statistics • Static IP/Dynamic IP
Wireless Security	• Captive Portal Authentication^§ • Access Control • Wireless Mac Address Filtering • Wireless Isolation Between Clients • SSID to VLAN Mapping • Rogue AP Detection • 802.1X Support • WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Transmission Power	• EU: < 20 dBm (2.4GHz, EIRP); < 23dBm (5 GHz, band1 & band 2, EIRP);< 30 dBm (5 GHz,band 3, EIRP); • US: < 30 dBm (2.4 GHz); < 30 dBm (5 GHz)

Management Features
Omada App	Yes
Restore & Backup	Yes
NTP	Yes
Centralized Management	• Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller
Cloud Access	Yes. Require the use of an Omada controller.
Email Alerts	Yes
LED ON/OFF Control	Yes
Management MAC Access Control	Yes
SNMP	v1, v2c, v3
System Logging Local/Remote Syslog	Yes
SSH	Yes
Web-based Management	Yes
Multi-site Management	Yes
Zero-Touch Provisioning	Yes. Requiring the use of Omada Cloud-Based Controller

OTHERS
Certification	CE, FCC, RoHS
Package Content	• Access Point EAP650 D30-Outdoor • Mounting Kits • Installation Guide
System Requirements	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
Environment	• Operating Temperature: -30–70 ℃ (-22–158 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing

For additional version information, please go to the support page.
