The Wireless Pump Controller is the perfect accessory if you want to control pumps remotely using your Smart Water system. Customised start/stop levels can be set directly via the WiFi LCD Keypad or WiFi Gateway, and also via the free iOS/Android app. Fully automatic "plug and play" pump operation is now possible with endless possibilities through the suite of options and settings that are offered. This version is rated at 12VDC

Key Features

• 230VAC, 12VDC and Change-Over (C/O) versions available
• Convenient wall mounting enclosure
• Long range wireless performance, tested up to 10km
• Up to 12 pump controllers can be added to a single system
• Name your pump controllers for ease of identification
• Fully programmable automatic pump operation
• Pump from tank to tank, or from an infinite source such as a bore
• Real-time clock functionality
• Range can be extended using the Active Repeater
• Controllable with the free App available on iOS and Android devices
• Simple DIY installation (12VDC versions) and operation

Specifications

• Powerful LoRa wireless technology offering range of up to 10km
• Wall mounting enclosure with marine grade ABS construction
• Weather resistant and IP65 rated
• 12VDC Input/output relay version
• 12VDC 25A Resistive contact rating (6370VA switching power)
• 208mm Dipole antenna with SMA connector
• Gold plated SMA female antenna connector
• Mounting kit included
