• Dual Band WiFi 6 Speeds up to 3000 Mbps – 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz.^‡
• Seamless Roaming with One Unified Network – Halo units work together to automatically switch between Halos as you move around your home with a single unified WiFi name and password.^†
• Whole Home Coverage – Blanket up to 5,000 ft² (460 m²) with high-speed WiFi, eliminating WiFi dead zones at your home.^‡
• Connect over 150 Devices – Provide fast and stable connections over 150 devices.^‡
• Easily Manage Your Home Network – Use the MERCUSYS App to quickly set up and manage your WiFi. You can also manage your kids’ online time and contents.
• 2.5 Gbps Multi-Gig Port – 1× 2.5 Gpbs and 2× Gigabit ports per Halo H85X unit for lightning-fast wired connections.^§

*Please note that the Halo H series and S series cannot work together.

Wireless

Wireless Standards

Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/b/g 2.4 GHz

WiFi Speeds : 2402 Mbps on 5 GHz, 574 Mbps on 2.4 GHz

Reception Sensitivity

2.4GHz:

11g 6Mbps:-96.5dBm

11g 54Mbps:-78dBm

11AX HE20 MCS0:-96.5dBm

11AX HE20 MCS11:-65dBm

11AX HE40 MCS0:-93.5dBm

11AX HE40 MCS11:-63dBm

5GHz:

11a 6Mbps:-96dBm

11a 54Mbps:-78dBm

11ac VHT20 MCS8:-74.5dBm

11ac VHT40 MCS9:-70.5dBm

11ac VHT80 MCS9:-66.5dBm

11AX HE20 MCS11:-66dBm

11AX HE40 MCS11:-63dBm

11AX HE80 MCS11:-61dBm

Transmission Power

2.4 GHz < 20dBm (EIRP)
5 GHz < 23dBm (EIRP)

Wireless Security : WPA-PSK/WPA2-PSK/WPA3

Mesh protocol : 802.11k/v/r



Hardware

Dimensions : 5 × 3.2 × 3.3 in (128 × 81 × 83.7 mm)

Interfaces

Halo H85X: 1× 2.5 Gbps Port + 2× 1 Gbps Ports

Halo H80X: 3× 1 Gbps Ports

(WAN/LAN auto-sensing)



Button : Reset button



Software

Operation Mode : Router, Access Point

Quality of Service : WMM

WAN Type : Dynamic IP/Static IP/PPPoE/L2TP/PPTP

Management : Local Management, Remote Management, Multi-Managers

Firewall Security : SPI Firewall

Protocols : Supports IPv4 and IPv6

Guest Network

2.4 GHz Guest Network,
5 GHz Guest Network

DHCP : Server, Client

Others

Package Contents

2-pack

1× Halo H85X Unit + 1× Halo H80X Unit
1× RJ45 Ethernet Cable
2× Power Adapters
Quick Installation Guide

Environment

Operating Temperature: 0°C~40°C (32°F~104°F)
Operating Humidity: 10%~90% Non-Condensing
Storage Humidity: 5%~90% Non-Condensing
