Name: Laird DCE10-H-001 DCE 10 x 10inch Aluminium Enclosure
Brand: Laird Connectivity
SKU: DCE-04
Price: 192.05 NZD
Availability: InStock

Laird DCE10-H-001 DCE 10 x 10inch Aluminium Enclosure

DCE-04

$192.05

Tax included.

14 items available

Select quantity

Description

Laird Technologies DCE10-H-001 DCE 10 x 10 Housing w/ Aluminum Door

Laird 10x10x2 Die Cast Aluminium Enclosure with 11 engineered knockouts Nema 6 Rated with pole mount bracket.

The die-cast enclosure can be pole or wall mounted. A heavy-duty tilt bracket is available for those installations requiring up or down tilt. Eleven (11) engineered knockouts are provided; 9 sized for N connectors and 2 sized for a cable feedthrough.

Features

11 engineered knockouts
Wide band antennas
Rugged and weatherproof
Hinged cover for easy maintenance
IP 67 Rated

Details
Product Code	DCE10-H-001
Knockouts (Qty 11)	Qty 3 0.810 Diameter hole Qty 8 0.625 Diameter hole, Double D
Knockout Locations	Qty 5 on bottom, Qty 3 on Right Side, Qty 2 on Top and Qty 1 in Back
Useable Interior Space	10 x 10 x 2 (181 x 156 x 51mm)
Mounting	1 to 2 pole using included bracket kit, or wall mount using user supplied screws
Cover Seal	High Performance EPDM Gasket
Solar Heat Rise	Internal Temperature 4 deg C above External Ambient
Overall Size (L x W x H)	12.5 x 10.4 x 3.6 (254 x 180 x 57mm)
Weight	5.75 lb.

Details
Enclosure	10x10x2 Die Cast Aluminium Included
Ethernet Cable Gland	Included
Mounting Hardware	Pole/Wall Mount Kit Included

Warranty

1 Year

Brand

Laird Connectivity

Restock ETA (if applicable)

Product Details

Specifications

Laird Connectivity
HeadingLaird DCE10-H-001 DCE 10 x 10inch Aluminium Enclosure

Description

Laird Technologies DCE10-H-001 DCE 10 x 10 Housing w/ Aluminum Door

Features

11 engineered knockouts
Wide band antennas
Rugged and weatherproof
Hinged cover for easy maintenance
IP 67 Rated

Details
Product Code	DCE10-H-001
Knockouts (Qty 11)	Qty 3 0.810 Diameter hole Qty 8 0.625 Diameter hole, Double D
Knockout Locations	Qty 5 on bottom, Qty 3 on Right Side, Qty 2 on Top and Qty 1 in Back
Useable Interior Space	10 x 10 x 2 (181 x 156 x 51mm)
Mounting	1 to 2 pole using included bracket kit, or wall mount using user supplied screws
Cover Seal	High Performance EPDM Gasket
Solar Heat Rise	Internal Temperature 4 deg C above External Ambient
Overall Size (L x W x H)	12.5 x 10.4 x 3.6 (254 x 180 x 57mm)
Weight	5.75 lb.
