Active Optical HDMI Cable PRS3 CP Series , 4K UHD 18Gbps – Kordz

Kordz Active Optical HDMI Cable PRS3 CP Series is designed to deliver 4K UHD 18Gbps performance. It features a narrow profile full metal die-cast shell assembly behind a unique grip tab HDMI connector for 3kg retention. Engineered to mitigate connector dropout potential, this cable is not suitable for repeated plug/unplug events.

This cable is 7.5m – 30m long, 4K/UHD 18Gbps certified by DPL Labs™, 18mm wide connector engineered to fit through a 1”/25mm conduit, reinforced internals for superior flexibility and pull strength during installation, light weight and flexible, no external power requirements, 100% of units tested on the production line for electrical continuity on all pins with additional 4K (2160p/60), 4:4:4, 17.82Gbps application test, high speed, all lengths, LSZH fire rated and comes with a 5 year warranty.

Features
Active Optical Cable (AOC) 7.5m – 30m, 4K/UHD 18Gbps certified by DPL Labs™
18mm wide connector engineered to fit through a 1”/25mm conduit
Reinforced internals for superior flexibility and pull strength during installation
Light weight & flexible
No external power requirements – works just like a 1m HDMI Cable
100% of units tested on the production line for electrical continuity on all pins with additional 4K (2160p/60), 4:4:4, 17.82Gbps application test
High Speed, all lengths
LSZH fire rated
5 Year Warranty
Technical Specifications

HDMI CERTIFICATION 7.5m – 30.0m ACTIVE OPTICAL

DPL Labs Certified Data Rate: 6.0Gbpsc, 17.82Gbps aggregate
Supported Data Rate: > 6.0Gbpsc,17.82Gbps (4K UHD)
Supported HDMI Clock: 27-340MHz

MECHANICAL

Cable Diameter: 5.00mm±0.2mm / 0.19” Ø
Mounting Length: 70.0mm/2.76”
Cable Bend Radius: 20.0mm/0.78”
Retention Force (nom): 9.8N (1kg / 2.2lbs) +10/-5%

CONSTRUCTION

TDMS: 4x Polymer Insulated Glass Fibres
Conductors: 32AWG Tinned copper wire
Insulation on TMDS: Polymer
Insulation on 4C + HEAC Pairs: Solid Polyolefin ? 2.0 relative permittivity
Shielding Overall: AL/Mylar
Cable Jacket Material: LSZH Composite, 7.5m-20m lengths
HDMI Connector Shell: Premium gauge folded steel, 1?” 24K Gold plated
HDMI Connector Pins: Solid OFC, 15?” 24K Gold plated
Active Technology: Directional, In-shell Optical Light Engine
Termination: Contactless IR induction soldering
HDMI Backshells: Orange & Charcoal powder coated with stoving varnish die-cast zinc alloy shell assembly
Product SKUs

K36232-0750-CH                              7.5 Meter

K36232-1000-CH                               10 Meter

K36232-1250-CH                             12.5 Meter

K36232-1500-CH                                15 Meter

K36232-1750-CH                             17.5 Meter

K36232-2000-CH                              20 Meter

K36232-2500-CH                               25 Meter

K36232-3000-CH                               30 Meter
