Description
HDMI Cable PRS3 Passive series, 4K UHD 18Gbps – Kordz
Kordz Passive PRS3 Series features a narrow profile full metal die-cast shell assembly behind a unique grip tab HDMI connector for 3kg receptacle retention capacity. PRS3 HDMI Cable 4K UHD Engineered to mitigate connector dropout potential – not suitable for repeated plug/unplug events.
Features DPL Certified 4K 18G-DC High Speed with Ethernet on all lengths. Passive in lengths 0.5m – 5m / 1.64’ – 16.4’ 18mm wide connector engineered to fit through 1”/25mm conduit. Induction soldered pin transitions for benchmark inter-terminal uniformity. Unique grip tab connectors with 3kg retention for permanent installations 100% of units tested on the production line for electrical continuity on all pins, with a full Bit Error Rate (BER) application test UL CMG fire rated in all lengths. Lifetime warranty.
Features
DPL Certified 4K 18G-DC
High Speed with Ethernet on all lengths
Passive in lengths 0.5m – 5m / 1.64’ – 16.4’
18mm wide connector engineered to fit through 1”/25mm conduit
Induction soldered pin transitions for benchmark inter-terminal uniformity
Unique grip tab connectors with 3kg retention for permanent installations
100% of units tested on the production line for electrical continuity on all pins, with a full Bit Error Rate (BER) application test
UL CMG fire rated in all lengths
Lifetime warranty
Technical Specifications
HDMI Certification ? 5.0m PASSIVE
HDMI CTS (Certified Test Specification) High Speed with Ethernet
DPL Labs Certified Data Rate .6.0Gbpsc, 17.82Gbps agg
Supported Data Rate ? 6.0Gbpsc, 17.82Gbps agg (4K UHD)
HDMI Clock 27-340MHz
Construction
Primary Conductors Solid 28-30 AWG OFC, length-dependent
Insulation TMDS Foam PE
4C + HEAC Pairs HDPE / Foamed-PE, length-dependent
Shielding TDMS Pairs Al / Mylar
Overall AL/Mylar + CU braid 80% coverage
Cable Jacket UL CMG fire-rated PVC
HDMI Connector Shell Pressed steel with dual grip tabs, 1µ” 24K Gold plated
HDMI Connector Pins Solid OFC, 15µ” 24K Gold plated
Termination Contactless IR induction soldering
HDMI Backshell Charcoal powder coated with stoving varnish die-cast zinc alloy shell assembly
Mechanical
Cable Diameter 0.5m – 3.0m: 30 AWG, 5.7mm/0.22” ø | 5m: 28 AWG, 6.5mm/0.26” ø
Mounting Depth 0.5m – 3.0m: 30AWG, 47.0mm/1.85” | 5m: 28 AWG, 56mm/2.20”
Cable Bend Radius 0.5m – 3.0m: 30 AWG, 24.0mm/0.94” | 5m: 28 AWG, 28.0mm/1.02”
Retention Force (nom) 29.7N (3kg / 6.6lbs) +10/-5%
Product SKUs
K36036-0050-CH 0.5 Meter
K36036-0100-CH 1 Meter
K36036-0150-CH 1.5 Meter
K36036-0200-CH 2 Meter
K36036-0300-CH 3 Meter
K36036-0500-CH 5 Meter
