Duinotech MEGA 2560 R3 Main Board Motor Controller (XC4461)

XC4461

$119.00

Tax included. Shipping calculated at checkout.

Select quantity
Description

XC4461

The TB6612 chips and supported electronics provide enough power to independently control four motors up to 12VDC with a driving current of up to 1.2A. The core ATMEGA2560-16AU processor supports 54 digital I/O ports (12 designed for motors) of which 15 can be used as PWM outputs (4 for motors), 16 analog inputs, and 4-channel serial communication ports (port 0 for programming). The board can also output 5V up to 3A across 3 channels to power external sensors or modules. Other features include 16MHz quartz crystal, a USB interface, DC power input, an ICSP plug and a reset button.


Features:

  • Arduino MEGA2560 compatible
  • Integrated 4-channel motor driver
  • Support for 7-12VDC battery
  • I2C Interface
  • USB Interface





Specifications





Specifications

Contains Button Cell : false
Length : 102mm
Packaged Volume : 0.17l
Packaged Weight : 0.06kg
Packaged Length : 12.9cm
Packaged Width : 6.9cm
Packaged Height : 1.9cm
Microcontroller : ATMEGA2560-16AU
Program memory : 256KB
Length : 102mm
Width : 66mm
Height : 18mm
Availability : Stocked item
