MB3938 Perfect for automotive and solar applications. Features: ·Universal DC input 12.0V-30.0V?0.2V For Solar/12.0V-15.0V?0.2V For car ·Compatible with Lead Acid,Li-ion, Gel and AGM batteries ·Fitted with colour-coded 50A high-current (Anderson-compatible) connectors ·High efficiency and high reliability ·Battery type select function ·Protection :Short Circuit/Over-temperature/Reverse polarity ·E24/CE/RoHs approved ·IP65-rated enclosure - dust tight and watertight against light pressure water spray Specifications: Input voltage      - Solar charging: 12.0V-30.0V±0.2V      - Car generator charging : 12.0V-15.8V±0.2V Output voltage      - GEL: 14.2V±0.2V      - CAL: 14.2V±0.2V      - STD: 14.4V±0.2V      - AGM: 14.8V±0.2V      - LiFePo4: 14.6V±0.2V Output current : 20A±0.5A Charging efficiency: Full load ?90%;Maximum efficiency reaches 97% Plugs to suit those supplied with the charger: Grey: PT4425 / Red: PT4426 / Yellow: PT4543 Working mode 1.    Solar charging (default priority) 2.    Car generator charging 3.    Five speed battery type adjustment Product size : 205x105x51mm (230mm long including mounting flanges) Product weight : 1.2KG  Note: the battery plug (red) will not connect to battery boxes as it is physically different to the plugs used on battery boxes. You will need to buy a plug set to change this plug housing to suit a battery box.
