HM3162 - Terminal Barrier PCB Transparent Cover 4 Way

HM3162

Barrier Material: Thermoplastic (UL=94V-0), Black
Terminals: Tint Plated Brass (Standard)
Screws: Nickel Plated Steel
Wire Range AWG: 12-22 STR
Cover Material: PC
Insulation withstands voltage AC 2000V/Min
Pole HD-12-? P HD-12-? PH
A (Px9.5)+1.4 (P+2)*9.5+1.4
B (P-1)*9.5 (P+1)*9.5





Specifications





Specifications

AC current rating : 25A

AC Voltage rating : 300V

DC current rating : 25A

Mounting Method : PCB

Attachment / Securing Method : Screw Down

Packaged Volume : 0.02l

Packaged Weight : 0.02kg

Packaged Length : 6cm

Packaged Width : 1.8cm

Packaged Height : 1.5cm

Type : Screw Terminal

Device : Terminal

Attachment Method : PCB

Number of Contacts : 4pc

Terminal Spacing : 9.5mm

Insulation Dielectric Voltage Rating : 2V

Insulation Resistance : 500M?
