Description
AC1591
1 Year Warranty
240V Mains Power
Vinyl records have become all the rage again but you may encounter a couple of issues which are addressed by this unit:
Firstly, vinyl records are manufactured in a way that requires frequency equalisation of the turntable output to make them sound right. Secondly, if your amplifier doesn’t have a phono input then you won’t be able to listen to your records.
There is a front panel switch to choose between input devices and a volume control on the front panel to adjust the output level as necessary as your turntables' cartridge may provide a lower or higher output than expected. All connections are made with the popular RCA connectors. Power is provided by an included mains adaptor.
Features:
- Volume control
- Stereo RCA output
- Function can be set to mix or IND
- Screw mount holes
- Power: 12VDC at 500mA
- Input Impedance : 47KO
- Output Impedance : 100O
- Phono Amplitude Gain : 40dB (@ 1KHz)
- Auxiliary Amplitude Gain : 6 dB
- Maximum Input : 50mVpp
- Output Level : 5Vpp
- Frequency Response : 20 Hz to 20KHz
- Signal to Noise Ratio : 70dB
Specifications
Specifications
| Width : 145mm |
| Height : 31mm |
| Depth : 96mm |
| Weight : 207g |
| Item Connection : Barrel Plug |
| Suitable PSU Included : true |
| Packaged Volume : 1.69l |
| Packaged Weight : 0.49kg |
| Packaged Length : 27.3cm |
| Packaged Width : 10cm |
| Packaged Height : 6.2cm |
| Input type : Audio |
| Input Connection : RCA Stereo Pair |
| Number of inputs : 2pc |
| Output Type : Audio |
| Output Connection : RCA Stereo Pair |
| Number of Outputs : 1pc |
| Dimension for : Other (details below) |
| Dimensions details : Mains Adaptor |
| Availability : Stocked item |
