The Briton 1130 Series is a non-handed, slimline closer designed to be used on commercial interior/exterior wooden and metal doors e.g. storeroom, office and toilet doors. The 1130 is an adjustable 2-6 strength closer to suit a range of door sizes. Door closing is hydraulically controlled, with adjustable back check and regulators to give the desired closing speed. The 1130 has a precision rack and pinion mechanism, and is easily mounted to the surface of door or the top jamb. Hold open and track arm versions also available.

Key Features

• Universal, fully reversible, non-handed door closer
• Closer body constructed from pressure die cast aluminium with steel rack and pinion
• Tested to 500,000 cycles
• Fully adjustable 2-6 strength regular arm, 2-4 strength track arm
• Factory set to strength 3
• Standard closer offers 3 installation options

                  - Regular (pull side)

                  - Top jamb (push side)

                  - Parallel arm (push side)

• Independent adjustment valves for controlling backcheck, closing and latching speeds
• Available in sprayed silver, satin stainless steel and matte black finish
• The 10 year warranty provides specifiers and users with assured quality and performance

Specifications

Data Sheet

Delivery

Expected delivery times:
- North Island 1-4 workings days
- South Island 2-5 working days
