PT-VZ470A
4400 Lumens WUXGA LCD Lamp Portable Projector
Get the best of both worlds in a projector that works brilliantly as a high-brightness portable for large boardrooms, meeting spaces, and classrooms, or as an easily managed ceiling installation solution thanks to single-cable DIGITAL LINK*. However it's used, there's full wireless* media casting support so everybody can serve punchy, pin-sharp pictures in well-lit spaces.
Key Features
- Boosted Picture Quality with Up to 5,500 lm and 16,000:1 Contrast
- 6-Colors Adjustment and Color Correction Functions
- Efficient Low-Maintenance Design
Boosted Picture Quality with Up to 5,500 lm and 16,000:1 Contrast
WUXGA (1920 x 1200 pixel) resolution native to the PT-VZ585N/VZ580/VZ470 brings crisp Full HD to meeting spaces and classrooms for immersive viewing. With brightness of up to 5,500 lm*1 and a class-leading 16,000:1 contrast ratio*2, your audience is treated to vivid colors, inky blacks, pure highlights, and clearly legible text reproduction even in bright conditions.
6-Colors Adjustment and Color Correction Functions
Correct slight color variations in the reproduction range of individual units set up for multi-projection. This is particularly useful for side-by-side configurations delivering ultra-wide-screen pictures. Very large images can be seamlessly presented in auditoriums and boardrooms.
Efficient Low-Maintenance Design
Less maintenance is not only good for your budget, but also the environment. Air filter replacement cycle is at a class-leading 7,000 hours, and the unit can be washed and reused twice*1 to minimize waste. Lamp life is also pushed out to 7,000 hours in ECO2 mode*2, meaning part refreshment can be performed together with filter maintenance to reduce downtime.
Specifications
| Power supply | AC 120 V, 50/60 Hz (North America), AC 110 V, 60 Hz (Taiwan), AC 100−240 V, 50/60 Hz (other countries) |
| Power consumption | 400 W [North America], 410 W [other countries] |
| Panel size | 0.64 inches (1.63 cm) (16:10 aspect ratio) |
| Display method | Transparent LCD panel (× 3, R/G/B) |
| Pixels | 2,304,000 (1920 × 1200) × 3, total of 6,912,000 pixels |
| Lens | 1.6x manual zoom (throw ratio: 1.09–1.77:1), manual focus F 1.60–2.12, f 15.30–24.64 mm |
| Lamp | 280 W UHM lamp × 1 |
| Screen size (diagonal) | 30−300 inches |
| Brightness *2 | 5,000 lm (input signal: PC, lamp power: Normal, picture mode: Dynamic, Daylight View: OFF, Auto Power Save: OFF) |
| Contrast *2 | 16,000:1 (all white/all black) (input signal: PC, lamp power: Normal, picture mode: Dynamic, Iris: On, Daylight View: OFF, Auto Power Save: OFF) |
| Resolution | 1920 x 1200 pixels |
| Supported RGB signal | XGA–WUXGA |
| Supported video signal | NTSC/PAL/SECAM, 480p/i, 720p, 1080p/i |
| Keystone correction range | Vertical: maximum ±25° (auto/manual, input: WUXGA), |
| Installation | Front ceiling / Front desk / Rear ceiling / Rear desk |
| Built-in speaker | 4.0 cm (1 1/16″ ) round shape × 1, output power: 10 W (monaural) |
| Dimensions (W x H x D) | 389 × 125*4 × 332 mm (15 5/16″ × 4 29/32″ *4 × 13 1/16″ ) |
| Weight*3 | Approximately 4.8 kg (10.6 lbs) |
| Operating environment | Operating temperature: 0−40 °C (32−104 °F)*5 (altitude: less than 1,200 m [3,937 ft]),<br>0−30 °C (32−86 °F) (altitude: 1,200−2,700 m [3,937−8,858 ft] ), Operating humidity: 20−80 % (no condensation) |
