KEY FEATURES
Long Range and Self-Centring Capability
High-Precision Hall Sensor
Aerospace-Grade CNC Aluminium Alloy The MOZA Z-Axis Module serves as a yaw control axis with a ±20° range and an extension kit adding 97mm in length. It features a 16-bit Hall sensor for precise control, aerospace-grade CNC aluminum alloy construction for durability, and a locking mechanism for flexible use. Easy to install and compatible with the MOZA ecosystem, it enhances the realism and versatility of your flight simulation setup.

Key Features

Long range and self-centring capability
The MOZA Z-axis module functions as a yaw control axis with a ±20° range, accommodating almost all aircraft models. It automatically returns to centre when unloaded.

High-precision hall sensor
Equipped with a 16-bit high-precision Hall sensor, the module detects and controls rotation with an accuracy of up to 0.005°. Its contactless design ensures stable and durable performance over time.

Aerospace-grade CNC aluminium alloy
Crafted entirely from aerospace-grade aluminium alloy using CNC machining and anodized surface treatment, the module offers robust durability and a premium metallic feel.

Extension functionality
The module can be used as an extension kit, adding 97mm in length to enhance the realism and professional feel of the flight experience.

Locking mechanism
It features a locking mechanism that disables the Z-axis function when only the extension function is needed.

Easy installation
Installation is straightforward: simply attach and hand-tighten the nut above the mounting stick for quick setup.

Open ecosystem compatibility
Compatible with the MOZA ecosystem and some third-party options, it provides versatility in setup configurations.

Specs
• Dimensions (mm) - 110×47.5×47.5
• Weight (g) - 260g
• Material - Aerospace-grade aluminium alloy
• Yaw Angle - ±20°
• Extension Length - 97mm
• Angle Sensor Resolution - 15-bit (32768 PPR)
• Self-Centring Function - Supported
• Locking Function - Supported
• Compatibility - Compatible with the MOZA ecosystem and some third-party options. Primary Format - Games
PC Gaming
Console compatibility
PC Gaming
Flight simulation product
Accessories
Colour
Black
Product Height (mm)
110
Product Width (mm)
47.5
Product Depth (mm)
47.5
Manufacturer's warranty
1 Year

2 Years

Moza
