New Sophisticated Design: A fully flat thin monitor with touch sensor keys. The doorphone has a gently curved, metallic-looking design that matches the home exterior. Also, the doorphone can be embedded in a wall by using the optional mount box.
Key Features:
- 2.2" DECT Wireless handset (320x240p)
- 100m Range (Line of sight)
- Rechargeable Ni-MH (AAAx2)
- AC Charger Adaptor (0.5A)
- Monitor Calling function
- Electronic Lock Release
- Monitor Calling function
Specifications
| Power source | Main body: Rechargeable battery AAA (R03) Ni-MH battery (1.2 V, 550 mAh)x2 |
|---|---|
| Dimensions (H x W x D) | Approx. 173 x 52 x 30 mm (excluding protruding sections) |
| Mass (weight) | Approx.160 g (including the batteries) |
| Operating environment | Ambient temperature: Approx. 0 ℃ to +40 ℃, Relative humidity (non-condensing): up to 90 % |
| Display size | 2.2-inch colour / QVGA (320 x 240 pixels) |
| Frequency range | 1.88 GHz to 1.90 GHz |
| RF transmission power | Approx. 10 mW (average powerper channel) 250 mW (max.) |
| Operating time | Standby use: approx. 80 hours*When used fully charged in an operating temperature of 20 °C. |
| Charging time | Approx. 8 hours*When the operating temperature is 20 °C. The charging time may increase when the operating temperature is lower than this. |
| Transmitting range | Approx. 100 m (line-of-sight distance between the main and wireless monitor) |
| External material | ABS resin |
Charger
| Power source | AC adaptor (5.5 V DC, 0.5 A) |
|---|---|
| Power consumption | Standby: 0.6 W * , Charing: 1.6 W*When the sub monitor with full-charged batteries is placed on the charger. |
| Dimensions (H x W x D) | Approx. 43 x 81 x 76 mm (excluding protruding sections) |
| Mass (weight) | Approx. 70 g (excluding the AC adaptor) |
| Operating environment | Ambient temperature: Approx. 0 ℃ to +40 ℃, Relative humidity (non-condensing): up to 90 % |
| External material | ABS resin |
