Description
The Rika RK300-02 Dust Sensor uses laser scattering to detect the existence of dust particle concentration in the air, the minimum it can detect is 1.0um particles. The RK300-02 has good consistency and stability. The RK300-02 can be connected to any device with an RS485 interface.
Need help selecting the right IoT solution?
.
Need help selecting the right IoT solution?
.
Features
- High Sensitivity
- Fast Response
- Low Power Consumption
- Excellent Stability
- Long Service Life
| Details | |
|---|---|
| SKU | RK300-02E |
| Sampling Object | PM1.0, PM2.5, PM10 |
| Range | 0-10000ug/m3 |
| Accuracy | 3%FS@25C |
| Power Supply | 12-24V |
| Output | RS485 |
| Power Consumption | <50mA@24V |
| Warm Up Time | 3min |
| Response Time | <90s |
| Temp Drift | <0.2%FS/C |
| Stability | <2%FS |
| Operating Temp | -20C - 50C |
| Shell Material | ABS |
| Details | |
|---|---|
Specifications
| Details | |
|---|---|
| SKU | RK300-02E |
| Sampling Object | PM1.0, PM2.5, PM10 |
| Range | 0-10000ug/m3 |
| Accuracy | 3%FS@25C |
| Power Supply | 12-24V |
| Output | RS485 |
| Power Consumption | <50mA@24V |
| Warm Up Time | 3min |
| Response Time | <90s |
| Temp Drift | <0.2%FS/C |
| Stability | <2%FS |
| Operating Temp | -20C - 50C |
| Shell Material | ABS |
