Description
IgniteNet’s new Mixed Media Converter is an evolutionary advance in media conversion. At its core, the Mixed Media Convertor converts 100/1000Mbps copper Ethernet to 1000Mbps fiber allowing for Passive POE in on the Ethernet port, while providing a 12-56v DC power tap for accessory connectivity. The Mixed Media Convertor can also be directly connected to a DC power cable and provide Passive POE out on it’s Ethernet RJ45 port offering unparalleled flexibility. The pluggable fiber optics port allows for flexible network configurations using SFP transceivers supplied by other manufacturers. The Mixed Media Converter can accommodate any type of miniGBIC (SFP) optical modules for easy migration from short-haul to long haul fiber connections by simply changing the optical module interface.
Features
- Low-cost outdoor fiber-to-ethernet and DC-to-PoE converter
- Wall or Pole Mountable
| Details | |
|---|---|
| Manufacturer's Code | ICC-MMC-WW |
| Output Power | 15 Watts |
| Interfaces | 1 Gigabit Ethernet PoE, 1 Gbps SFP Cage, DC Terminal |
| Temperature Range | -40 to +70° C |
| DC In | 12-56V |
| PoE Out | 15 W + (1,2 & 4,5) - (3,6 & 7,8) |
| Max Power consumption | 4 W Max |
| Pole Diameter | 25-100mm |
| Dimensions | 258 x 119 x 44 mm |
| Weather Rating | IP-55 |
| Details | |
|---|---|
| Mounting | Wall mount Bracket |
Specifications
| Details | |
|---|---|
| Manufacturer's Code | ICC-MMC-WW |
| Output Power | 15 Watts |
| Interfaces | 1 Gigabit Ethernet PoE, 1 Gbps SFP Cage, DC Terminal |
| Temperature Range | -40 to +70° C |
| DC In | 12-56V |
| PoE Out | 15 W + (1,2 & 4,5) - (3,6 & 7,8) |
| Max Power consumption | 4 W Max |
| Pole Diameter | 25-100mm |
| Dimensions | 258 x 119 x 44 mm |
| Weather Rating | IP-55 |
