Features
- High efficiency with 80 PLUS Bronze certification
- 24/7 continuous power output with 40℃ operating temperature
- Class-leading single +12V rail
- Multiple protection circuitry
- Silent running 120mm fan with 18 dBA
- PCI-E 8pin and PCI-E 6pin connectors support
- Active PFC
Warranty
36 Month Return to Base Warranty
Specifications
| Max. DC Output | 500W |
|---|---|
| Power Density | 277W per litre |
| Combined +3.3, +5V | 100W |
| Combined +12V | 456W |
| Input Voltage | 100V ~ 264Vrms |
| Input Frequency Range | 47Hz ~ 64Hz |
| Protection | Over power protection Over voltage protection Short circuit protection |
| Connectors | 1 x 24 / 20-Pin motherboard connector（”500mm”） 1 x 8 / 4-Pin EPS / ATX 12V connector（”600mm”） 2 x 8/6-Pin PCIE connector（”500mm/100mm”） 6 x SATA connector（"500mm /100mm / 100mm" x 2） 3 x 4-Pin Peripheral connector（”500mm / 100mm / 100mm”） |
| Cooling System | Single 120mm Silent Fan |
| Form Factor | ATX |
| Noise Level | 18dBA minimum |
| Dimensions | 150 mm (W) x 86 mm (H) x 140 mm (D) |
| Weight | 1.44kg |
