Description
Nuclias Connect Hub
DNH-100
A compact, cost-effective solution that can manage up to 100 Nuclias Connect access points without the need of extra server/pc
- Manage up to 100 Wireless Access Points (APs) simultaneously or individually
- Fully equipped with a 1000Base-T Ethernet Port, a USB 3.0 Port, and a Micro SD Slot
- Easy to manage with D-Link’s centralized management software-based solution, Nuclias Connect
- Auto managed frequency bands and L2/L3 AP discovery makes sure connected devices are getting the best coverage AVailable
- Manage multiple VLANs for enhanced network management and SSID setups for greater control
- Support for IEEE 802.3ab/u/x standards allows seamless integration with other systems
- Single Sign-On sAVes time, cutting out the endless entering of user login details
- Support for Command Line Interface (CLI)
- Support for NAT Passthrough which allows multi-site management
Specifications
10/100/1000Base-T | 1 |
---|---|
Optional 10G Uplink Module | N/A |
Combo 10/100/1000Base-T/SFP | N/A |
Console Port | RJ-45 |
USB Port (2.0) | 1 (3.0) |
Maximum Access Points per unit (default/ upgrade*) | 100 |
Maximum Access Points per cluster (default/ upgrade*) | 100 |
AP Auto Discovery | Yes |
AP Monitoring | Yes |
AP Authentication by External RADIUS | Yes |
AP Authentication by Local Database | Yes |
Auto Power Management | Yes |
Auto Channel Management | Yes |
Centralized Firmware Upgrade | Yes |
Visualization Management | Yes |
Remote AP Reboot | Yes |
Connection mode between controller and AP | Bridge |
Multi-tenant | Yes |
NAT pass through (Controller can manage APs behind NAT) | Yes |
Device Clustering | No |
Device Clustering per Group | No |
Configuration Push within Group | Yes |
802.3af PoE | N/A |
802.3at PoE | N/A |
PoE Power budget | N/A |
PoE Power budget with RPS | N/A |
802.3at (Per Port) | N/A |
Captive Portal | Yes |
External User Database - RADIUS | Yes |
External User Database - POP3 | Yes |
External User Database - LDAP | Yes |
Local User Database | Yes |
TACACS+ | No |
802.1X | Yes |
Client Monitoring | Yes |
Client Classicification | Yes |
Ad-hoc Client Monitoring | No |
Location Tracking | No |
L2 Fast Roaming | No |
L3 Fast Roaming | No |
TKIP/AES Encryption | Yes |
WPA/WPA2-Enterprise | Yes |
WPA/WPA2-Personal | Yes |
Rouge AP Detection & Mitigation | No |
Rouge Client Detection & Mitigation | No |
WLAN MAC Filtering | Yes |
Hidden SSID | Yes |
AP Station Isolation | Yes |
AP Classification | Yes |
WIDS | No |
Wireless Multimedia (WMM) | Yes |
802.1p Priority Queues | No |
CoS-based QoS | No |
Per-port Traffic Shaping | N/A |
Per-flow Bandwidth Control | No |
Per-queue Minimum Bandwidth Guarantee | No |
802.1Q VLAN Tagging | Yes |
802.1V Subnet-based VLAN | No |
MAC-based VLAN | No |
Port-based VLAN | N/A |
GVRP | N/A |
Static VLAN | Yes |
Voice VLAN | N/A |
VLAN Numbers | N/A |
Dynamic VLAN | Yes |
Double VLAN (Q-in-Q) | N/A |
Switching Capacity | N/A |
Max. Packet Forwarding Rate | N/A |
MAC Address Table Size | N/A |
Packet Buffer Size | N/A |
Telnet Client | No |
Telnet Server | Yes |
TFTP Server | No |
TFTP Client | No |
SNMP (v1,v2c,v3) | No |
SNTP | No |
NTP | Yes |
sFlow | No |
Multiple Configuration Files | Yes |
Dual Images | Yes |
RMONv1 | No |
DHCP / BootP Client | No |
DHCP Server | No |
DHCP Relay | No |
SYSLOG | Yes |
SSH | Yes |
HTTP | No |
HTTPS | Yes |
Command Line Interface (CLI) | Yes |
802.1D Spanning Tree (STP) | N/A |
802.1w Rapid Spanning Tree (RSTP) | N/A |
802.1s Multiple Spanning Tree (MSTP) | N/A |
IGMP Snooping | N/A |
LLDP-MED | N/A |
Many-to-One Mirroring | N/A |
One-to-One Mirroring | N/A |
MLD Snooping | N/A |
Maximum Jumbo Frame (KB) | N/A |
IPv6 Static Route | N/A |
IPv4 Static Route | N/A |
Routing Table Size | N/A |
ARP Proxy | N/A |
OSPF | N/A |
RIP v1/ v2 | N/A |
LAN MAC Filtering | N/A |
Broadcast Storm Control | N/A |
DHCP Filtering | N/A |
DHCP Snooping | N/A |
Dynamic ARP Inspection ( DAI ) | N/A |
802.3ad Link Aggregation | N/A |
Link Aggregation Group Per Device | N/A |
Max Port Per Link Aggregation Group | N/A |
VRRP | N/A |
WAN Fail-over** | No |
Firewall Policy | No |
Numbers of Firewall Policy | N/A |
Policy-based route | No |
NAT, PAT | No |
Outbound Load Balancing | No |
Dynamic DNS | No |
IPSec VPN Tunnel | No |
PPTP / L2TP VPN Tunnel | No |
IPSec Nat Traversal | No |
VPN Tunnel Keep Alive | No |
Dead Peer Detection | No |
Hub and Spoke | No |
SSL VPN Tunnel | No |
Encryption Methods (DES/3DES/AES/Twofish/Blowfish/CAST-128/Null) | No |
IP Encapsulating Security Payload (ESP) | No |
IP Authentication Header(AH) | No |
SSL Encryption Methods (DES/3DES/AES) | No |
SSL Message Integrity (MD5/SHA1) | No |
Static Web Content Filtering - Key word / URL | No |
Dynamic Web Content Filtering ( Category) | No |
Rackmount | 19 inch |
Dimension | 190 x 100 x 31 mm |
Weight | 529 g |
Operation Temperature | 0 ~ 40 °C |
Storage Temperature | - 20 ~ 70 °C |
Operation Humidity | 10% ~ 90% RH |
Storage Humidity | 5% ~ 95% RH |
Power Supply | AC:100 ~ 240 V, 50/60 Hz |
Power Consumption | 6.5 W |
Redundant Power Supply Support | No |
Redundant Power Supply Module | No |
Heat Dispassion | N/A |
Acoustic | 0 dB (fanless) |
MTBF | 260,000 hrs |
FCC | Class B |
CE | Yes |
C-Tick | Yes |
VCCI | Yes |
BSMI | Yes |
ICES-003 | N/A |
EN 60601-1-2 | No |
Safety Certifications (cUL) | Yes |
Safety Certifications (CB) | Yes |
Safety Certifications (LVD (En60950-1) ) | Yes |
AP License Upgrade | N/A |
Advanced Feature Lincense Upgrade | N/A |
